Electronics Cooling






Unsere Produktauswahl

Electronics Cooling – auf einen Blick.

Unser gesamtes Produktsortiment

Um das Produktportfolio eines bestimmten Standorts anzuzeigen, wählen Sie bitte das Unternehmen aus:

Single-Phase Cold Plates

Thermosyphons

We design and manufacture the best performing and most cost effective cold plates for liquid cooling available today. Our innovative cold plates use our patented Micro Deformation Technology (MDT) inside and typically feature friction stir welded (FSW) construction however other joining methods such as vacuum brazing are available.  We offer two lines of standard cold plates as well as semi custom and custom cold plate options.


Our cold plates are perfect for: high power electronics, inverters, DC-DC converters, wind inverters, solar inverters, automotive, hybrid and electric vehicles, waste heat recovery, thermal electric (TEC), MRI amplifiers, power supplies, variable speed drives, locomotive, traction drives, agriculture machinery, lasers, RF amplifiers, data center, CPU, GPU, and chillers.

Learn more:

Micro Deformation Technology (MDT)
Friction Stir Welding (FSW)
Manufacturing Technologies



Werkstoffe

High Performance, Scalable and Customizable Cold Plates

Our 4000 Series cold plates are the next evolution of our standard cold plate line. The 4000 series are designed to fit the most common power electronic footprints and can be easily customized for other needs.

The MDT™ pin fin inside, extruded and friction stir welded construction, and balanced parallel cooling offers lower thermal resistance, lower pressure drop, and competitive pricing.

If these “off the shelf” standard cold plates do not meet your requirements, please contact us to discuss custom cold plate options to meet the needs of your specific application.



Part Number# of ModulesSurface EnchancementPort FittingModule Bolt Pattern (L x W mm)Dimension (L x W x H mm)Drawing3D Model
CP-E-4009-S3XJ320 FPI MDTJ192648 x 93225 x 130 x 204009 Drawing4009 CAD
CP-E-4012-S3XJ320 FPI MDTJ192644.75 x 71.75190 x 90 x 204012 Drawing4012 CAD
CP-E-4013-S3XJ320 FPI MDTJ192686 x 127321 x 150 x 204013 Drawing4013 CAD



cold plates rendering



MicroCool Cold Plate Advantage

Wieland MicroCool friction stir welded cold plates with MDT® pin fin inside offer 30% better performance with less pressure drop than most cold plate designs on the market today.

We offer both standard and custom designs that are often lower cost than our competitors giving you more performance for your money.

  • 30% less thermal resistance
  • 5X less pressure drop
  • Balanced parallel cooling
  • Similar cost
  • 2-day shipping on standard products
  • 4-6 weeks shipping on custom designs



Learn more


Die in diesem Dokument angegebenen Produkt- und Werkstoffeigenschaften sind allgemeiner Art und dienen lediglich allgemeinen Informationszwecken. Aussagen über die Eignung von Produkten und Werkstoffen für bestimmte Anwendungen beruhen auf typischen Anforderungen und ersetzen keinesfalls eine fachkundige Beratung. Wieland übernimmt keinerlei Haftung für Schäden, die aus dem Vertrauen auf die vorliegend bereitgestellten Informationen resultieren.

Wieland Microcool brings decades of experience both engineering and manufacturing enhanced boiling surfaces. Our MDT™ technology fills the unique application of both pool boiling or flow boiling.

  • 245fa Refrigerant
  • 3003 and 1100 Aluminum
  • Brazed Construction
  • Micro-Channel Evaporator
  • Multiport tube/Folded Fin Condensor

Able to cool a 100W processor case to 70C with an air Inlet temp of 20C with only a 10 CFM (1.5 m/s velocity) flow.

Learn more


Die in diesem Dokument angegebenen Produkt- und Werkstoffeigenschaften sind allgemeiner Art und dienen lediglich allgemeinen Informationszwecken. Aussagen über die Eignung von Produkten und Werkstoffen für bestimmte Anwendungen beruhen auf typischen Anforderungen und ersetzen keinesfalls eine fachkundige Beratung. Wieland übernimmt keinerlei Haftung für Schäden, die aus dem Vertrauen auf die vorliegend bereitgestellten Informationen resultieren.
