Kupfer Legierungen
Wir bieten eine große Auswahl an Kupferlegierungen an.
Unsere Produktauswahl
Kupfer Legierungen – auf einen Blick.
Unser gesamtes Produktsortiment
Um das Produktportfolio eines bestimmten Standorts anzuzeigen, wählen Sie bitte das Unternehmen aus:
Kupfer
Hochleistungslegierungen
Kupfer-Nickel-Legierungen
Gusslegierungen
Niedrig legiertes Kupfer
Produkte
| Wieland | EN Bezeichnung | EN-Nr. | ASTM-UNS-Nr. | JIS-Nr. |
|---|---|---|---|---|
| K04 | - | - | C15500 | |
| K11 | Cu-OF | CW008A | C10200 | |
| K19 | Cu-DHP | CW024A | C12200 | C1220 |
| K32 | Cu-ETP | CW004A | C11000 | C1100 |
| KG1 | - | - | C19700 | |
| KG4 | - | - | C19020 | |
| KG6 | - | - | C19720 | |
| KG9 | - | - | C19025 |
| Wieland | EN Bezeichnung | EN-Nr. | ASTM-UNS-Nr. |
|---|---|---|---|
| Elmedur B2 | CuBe2 | CW101C | C17200 |
| Elmedur HA | CuCoNiBe | CW103C | ~C17500 |
| Elmedur HC | CuNi2Be | CW110C | C17510 |
| Elmedur NCS | CuNi2SiCr* | ~CW111C* | C18000 |
| Elmedur X | CuCrZr | CW106C | C18150 |
| Wieland | EN Bezeichnung | EN-Nr. | ASTM-UNS-Nr. | JIS-Nr. |
|---|---|---|---|---|
| Elmedur B2 | CuBe2 | CW101C | C17200 | |
| Elmedur HA | CuCoNiBe | CW103C | ~C17500 | |
| Elmedur HC | CuNi2Be | CW110C | C17510 | |
| Elmedur NCS | CuNi2SiCr* | ~CW111C* | C18000 | |
| Elmedur X | CuCrZr | CW106C | C18150 | |
| Elmedur Z | CuZr | CW120C | C15000 | |
| K08 | Cu-OFE | CW009A | C10100 | |
| K12 | Cu-HCP | CW021A | C10300 | |
| K20/K21/K28 | Cu-DHP | CW024A | C12200 | |
| K30 | Cu-OF | CW008A | C10200 | |
| K32 | Cu-ETP | CW004A | C11000 | C1100 |
| K96 | CuCo1Ni1Be | CW103C | - |
| Wieland | EN Bezeichnung | EN-Nr. | ASTM-UNS-Nr. |
|---|---|---|---|
| Elmedur B2 | CuBe2 | CW101C | C17200 |
| Elmedur HA | CuCoNiBe | CW103C | ~C17500 |
| Elmedur HC | CuNi2Be | CW110C | C17510 |
| Elmedur NCS | CuNi2SiCr* | ~CW111C* | C18000 |
| Elmedur X | CuCrZr | CW106C | C18150 |
| Elmedur Z | CuZr | CW120C | C15000 |
| Wieland | EN Bezeichnung | EN-Nr. | ASTM-UNS-Nr. | JIS-Nr. |
|---|---|---|---|---|
| Elmedur B2 | CuBe2 | CW101C | C17200 | |
| Elmedur HA | CuCoNiBe | CW103C | ~C17500 | |
| Elmedur HC | CuNi2Be | CW110C | C17510 | |
| Elmedur NCS | CuNi2SiCr* | ~CW111C* | C18000 | |
| Elmedur X | CuCrZr | CW106C | C18150 | |
| Elmedur Z | CuZr | CW120C | C15000 | |
| K08 | Cu-OFE | CW009A | C10100 | |
| K12 | Cu-HCP | CW021A | C10300 | |
| K18 | Cu-ETP | CW004A | C11000 | |
| K20/K21/K28 | Cu-DHP | CW024A | C12200 | |
| K30 | Cu-OF | CW008A | C10200 | |
| K32 | Cu-ETP | CW004A | C11000 | C1100 |
| K96 | CuCo1Ni1Be | CW103C | - |
| Wieland | EN Bezeichnung | EN-Nr. | ASTM-UNS-Nr. | JIS-Nr. |
|---|---|---|---|---|
| Elmedur B2 | CuBe2 | CW101C | C17200 | |
| Elmedur HA | CuCoNiBe | CW103C | ~C17500 | |
| Elmedur HC | CuNi2Be | CW110C | C17510 | |
| Elmedur NCS | CuNi2SiCr* | ~CW111C* | C18000 | |
| Elmedur X | CuCrZr | CW106C | C18150 | |
| Elmedur Z | CuZr | CW120C | C15000 | |
| K08 | Cu-OFE | CW009A | C10100 | |
| K12 | Cu-HCP | CW021A | C10300 | |
| K18 | Cu-ETP | CW004A | C11000 | |
| K20/K21/K28 | Cu-DHP | CW024A | C12200 | |
| K30 | Cu-OF | CW008A | C10200 | |
| K32 | Cu-ETP | CW004A | C11000 | C1100 |
| K44 | - | - | C19140 / C19150 | |
| K96 | CuCo1Ni1Be | CW103C | - | |
| KD1 | - | CW102C | - | |
| KD3 | - | CW118C | - |
| Wieland | EN Bezeichnung | EN-Nr. | ASTM-UNS-Nr. | JIS-Nr. |
|---|---|---|---|---|
| Elmedur NCS | CuNi2SiCr* | ~CW111C* | C18000 | |
| Elmedur X | CuCrZr | CW106C | C18150 | |
| K12 | Cu-HCP | CW021A | C10300 | |
| K16 | Cu-ETP1 | CW003A | - | |
| K20/K21/K28 | Cu-DHP | CW024A | C12200 | |
| K30 | Cu-OF | CW008A | C10200 | |
| K32 | Cu-ETP | CW004A | C11000 | C1100 |
| KA1 | CuAg0,10P | CW016A | - |
| Wieland | EN Bezeichnung | EN-Nr. | ASTM-UNS-Nr. | JIS-Nr. |
|---|---|---|---|---|
| Elmedur B2 | CuBe2 | CW101C | C17200 | |
| Elmedur HA | CuCoNiBe | CW103C | ~C17500 | |
| Elmedur HC | CuNi2Be | CW110C | C17510 | |
| Elmedur NCS | CuNi2SiCr* | ~CW111C* | C18000 | |
| Elmedur X | CuCrZr | CW106C | C18150 | |
| K09 | Cu-OFE | CW009A | C10100 | C1011 |
| K10 | Cu-OFE | CW009A | - | |
| K11 | Cu-OF | CW008A | C10200 | |
| K12 | Cu-HCP | CW021A | C10300 | |
| K14 | Cu-PHC | CW020A | C10300 | |
| K15 | Cu-DLP | CW023A | C12000 | C1201 |
| K18 | Cu-ETP | CW004A | C11000 | |
| K19 | Cu-DHP | CW024A | C12200 | C1220 |
| K30 | Cu-OF | CW008A | C10200 | |
| K32 | Cu-ETP | CW004A | C11000 | C1100 |
| K96 | CuCo1Ni1Be | CW103C | - |
| Wieland | EN Bezeichnung | EN-Nr. | ASTM-UNS-Nr. | JIS-Nr. |
|---|---|---|---|---|
| Elmedur B2 | CuBe2 | CW101C | C17200 | |
| Elmedur HA | CuCoNiBe | CW103C | ~C17500 | |
| Elmedur HC | CuNi2Be | CW110C | C17510 | |
| Elmedur NCS | CuNi2SiCr* | ~CW111C* | C18000 | |
| Elmedur X | CuCrZr | CW106C | C18150 | |
| Elmedur Z | CuZr | CW120C | C15000 | |
| K08 | Cu-OFE | CW009A | C10100 | |
| K12 | Cu-HCP | CW021A | C10300 | |
| K20/K21/K28 | Cu-DHP | CW024A | C12200 | |
| K30 | Cu-OF | CW008A | C10200 | |
| K32 | Cu-ETP | CW004A | C11000 | C1100 |
| K96 | CuCo1Ni1Be | CW103C | - |
| Wieland | EN Bezeichnung | EN-Nr. | ASTM-UNS-Nr. | JIS-Nr. |
|---|---|---|---|---|
| Elmedur HC | CuNi2Be | CW110C | C17510 | |
| Elmedur X | CuCrZr | CW106C | C18150 | |
| K09 | Cu-OFE | CW009A | C10100 | C1011 |
| K10 | Cu-OFE | CW009A | - | |
| K11 | Cu-OF | CW008A | C10200 | |
| K12 | Cu-HCP | CW021A | C10300 | |
| K14 | Cu-PHC | CW020A | C10300 | |
| K15 | Cu-DLP | CW023A | C12000 | C1201 |
| K19 | Cu-DHP | CW024A | C12200 | C1220 |
| K30 | Cu-OF | CW008A | C10200 | |
| K32 | Cu-ETP | CW004A | C11000 | C1100 |
| Wieland | EN Bezeichnung | EN-Nr. | ASTM-UNS-Nr. | JIS-Nr. |
|---|---|---|---|---|
| Elmedur HC | CuNi2Be | CW110C | C17510 | |
| Elmedur NCS | CuNi2SiCr* | ~CW111C* | C18000 | |
| Elmedur X | CuCrZr | CW106C | C18150 | |
| K20/K21/K28 | Cu-DHP | CW024A | C12200 | |
| K32 | Cu-ETP | CW004A | C11000 | C1100 |
| Wieland | EN Bezeichnung | EN-Nr. | ASTM-UNS-Nr. |
|---|---|---|---|
| K44 | - | - | C19140 / C19150 |
* Werkstoff in EN nicht genormt
Produkte
| Wieland | EN Bezeichnung | EN-Nr. | ASTM-UNS-Nr. |
|---|---|---|---|
| K55 | CuNi3Si1Mg* | - | C70250 |
| K58 | CuNi3Si1Mg | - | C70250 |
| K76 | CuNiSiP* | - | C19010 |
| K82 | - | - | C15100 |
| K88 | CuCrAgFeTiSi* | - | C18080 |
| Wieland | EN Bezeichnung | EN-Nr. | ASTM-UNS-Nr. |
|---|---|---|---|
| K55 | CuNi3Si1Mg* | - | C70250 |
| K57 | CuNi1Co1Si* | - | C70350 |
| K58 | CuNi3Si1Mg | - | C70250 |
| K73 | CuNi1ZnSi* | - | C19005 |
| K75 | CuCrSiTi* | - | C18070 |
| K76 | CuNiSiP* | - | C19010 |
| K82 | - | - | C15100 |
| K88 | CuCrAgFeTiSi* | - | C18080 |
| Wieland | EN Bezeichnung | EN-Nr. | ASTM-UNS-Nr. |
|---|---|---|---|
| K55 | CuNi3Si1Mg* | - | C70250 |
| K57 | CuNi1Co1Si* | - | C70350 |
| K58 | CuNi3Si1Mg | - | C70250 |
| K73 | CuNi1ZnSi* | - | C19005 |
| K75 | CuCrSiTi* | - | C18070 |
| K76 | CuNiSiP* | - | C19010 |
| K82 | - | - | C15100 |
| K88 | CuCrAgFeTiSi* | - | C18080 |
| Wieland | EN Bezeichnung | EN-Nr. | ASTM-UNS-Nr. |
|---|---|---|---|
| K55 | CuNi3Si1Mg* | - | C70250 |
* Werkstoff in EN nicht genormt
Produkte
| Wieland | EN Bezeichnung | EN-Nr. | ASTM-UNS-Nr. |
|---|---|---|---|
| L23 | - | - | C70600 |
| L24 | - | - | C71000 |
| L26 | - | - | C71300 |
| L27 | - | - | C71500 |
| L49 | CuNi9Sn2 | CW351H | C72500 |
| Wieland | EN Bezeichnung | EN-Nr. | ASTM-UNS-Nr. |
|---|---|---|---|
| L10/L13/L15 | CuNi10Fe1Mn | CW352H | C70600 |
| L30 | CuNi30Mn1Fe | CW354H | C71500 |
| eco LV3® | CuNi9Sn6* | - | C72700 |
| Wieland | EN Bezeichnung | EN-Nr. | ASTM-UNS-Nr. |
|---|---|---|---|
| L10/L13/L15 | CuNi10Fe1Mn | CW352H | C70600 |
| L30 | CuNi30Mn1Fe | CW354H | C71500 |
| eco LV3® | CuNi9Sn6* | - | C72700 |
| Wieland | EN Bezeichnung | EN-Nr. | ASTM-UNS-Nr. |
|---|---|---|---|
| L10/L13/L15 | CuNi10Fe1Mn | CW352H | C70600 |
| L30 | CuNi30Mn1Fe | CW354H | C71500 |
| eco LV3® | CuNi9Sn6* | - | C72700 |
| Wieland | EN Bezeichnung | EN-Nr. | ASTM-UNS-Nr. |
|---|---|---|---|
| L10 | CuNi10Fe1Mn | CW352H | C70600 |
| L49 | CuNi9Sn2 | CW351H | C72500 |
| L96 | CuNi9Sn6 | - | - |
| Wieland | EN Bezeichnung | EN-Nr. | ASTM-UNS-Nr. |
|---|---|---|---|
| L10/L13/L15 | CuNi10Fe1Mn | CW352H | C70600 |
| L30 | CuNi30Mn1Fe | CW354H | C71500 |
| eco LV3® | CuNi9Sn6* | - | C72700 |
| Wieland | EN Bezeichnung | EN-Nr. | ASTM-UNS-Nr. |
|---|---|---|---|
| eco LV3 | CuNi9Sn* | - | C72700 |
| Wieland | EN Bezeichnung | EN-Nr. | ASTM-UNS-Nr. |
|---|---|---|---|
| L10/L13/L15 | CuNi10Fe1Mn | CW352H | C70600 |
| L30 | CuNi30Mn1Fe | CW354H | C71500 |
| eco LV3® | CuNi9Sn6* | - | C72700 |
* Werkstoff in EN nicht genormt
| Wieland | EN Bezeichnung | EN-Nr. | ASTM-UNS-Nr. |
|---|---|---|---|
| G71 | - | - | C65400 |
| G72 | - | - | C65500 |
| Wieland | EN Bezeichnung | EN-Nr. | ASTM-UNS-Nr. |
|---|---|---|---|
| G01 | - | - | - |
| G05 | CuSn5Zn5Pb5-C-GC | CC491K | - |
| G07/G08 | CuSn7Zn4Pb7-C | CC493K | - |
| G10 | CuSn10-C | CC480K | - |
| G12/G13 | CuSn12-C | CC483K | - |
| G21 | CuSn10Pb10-C-GC | CC495K | - |
| G22 | CuSn7Pb15-C | CC496K | - |
| G91 | CuSn11Pb2-C-GC | CC482K | - |
| GA1 | CuSn11Pb2-C-GC | CC481K | - |
| GB1 | CuSn12Ni2-C | CC484K | - |
| GD1 | CuSn5Zn5Pb2-C-GC | CC499K | - |
| eco GS1® | CuSn4Zn2PS-C-GC* | - | - |
* Werkstoff in EN nicht genormt
Produkte
| Wieland | EN Bezeichnung | EN-Nr. | ASTM-UNS-Nr. |
|---|---|---|---|
| K65 | CuFe2P | CW107C | C19400 |
| K80 | CuFe0,1P* | - | C19210 |
| K85 | - | - | C19700 |
| Wieland | EN Bezeichnung | EN-Nr. | ASTM-UNS-Nr. |
|---|---|---|---|
| K41 | CuNi1Pb1P* | - | C19150 / C19160 |
| K52 | CuNi2Si | CW111C | C70260 |
| K53 | CuNi2SiS* | - | - |
| K54 | CuNi2SiCr* | - | C81540 |
| K60 | CuCr1Zr | CW106C | C18150 |
| K61 | CuCr1Zr | CW106C | C18200 |
| K65 | CuFe2P | CW107C | C19400 |
| K81 | CuSn0,15 | CW117C | C14415 |
| KC1 | CuPb1P | CW113C | C18700 |
| eco KS2® | CuSP | CW114C | C14700 |
| eco KS4® | CuNi1SP* | - | - |
| Wieland | EN Bezeichnung | EN-Nr. | ASTM-UNS-Nr. |
|---|---|---|---|
| K41 | CuNi1Pb1P* | - | C19150 / C19160 |
| K52 | CuNi2Si | CW111C | C70260 |
| K53 | CuNi2SiS* | - | - |
| K54 | CuNi2SiCr* | - | C81540 |
| K60 | CuCr1Zr | CW106C | C18150 |
| K61 | CuCr1Zr | CW106C | C18200 |
| K65 | CuFe2P | CW107C | C19400 |
| K81 | CuSn0,15 | CW117C | C14415 |
| KC1 | CuPb1P | CW113C | C18700 |
| eco KS2® | CuSP | CW114C | C14700 |
| eco KS4® | CuNi1SP* | - | - |
| Wieland | EN Bezeichnung | EN-Nr. | ASTM-UNS-Nr. |
|---|---|---|---|
| K41 | CuNi1Pb1P* | - | C19150 / C19160 |
| K52 | CuNi2Si | CW111C | C70260 |
| K53 | CuNi2SiS* | - | - |
| K54 | CuNi2SiCr* | - | C81540 |
| K60 | CuCr1Zr | CW106C | C18150 |
| K61 | CuCr1Zr | CW106C | C18200 |
| K65 | CuFe2P | CW107C | C19400 |
| K81 | CuSn0,15 | CW117C | C14415 |
| KC1 | CuPb1P | CW113C | C18700 |
| eco KS2® | CuSP | CW114C | C14700 |
| eco KS4® | CuNi1SP* | - | - |
| Wieland | EN Bezeichnung | EN-Nr. | ASTM-UNS-Nr. |
|---|---|---|---|
| K41 | CuNi1Pb1P* | - | C19150 / C19160 |
| K42 | CuZn0,5 | CW119C | - |
| K52 | CuNi2Si | CW111C | C70260 |
| K53 | CuNi2SiS* | - | - |
| K54 | CuNi2SiCr* | - | C81540 |
| K60 | CuCr1Zr | CW106C | C18150 |
| K61 | CuCr1Zr | CW106C | C18200 |
| K65 | CuFe2P | CW107C | C19400 |
| K80 | CuFe0,1P* | - | C19210 |
| K81 | CuSn0,15 | CW117C | C14415 |
| K85 | - | - | C19700 |
| KC1 | CuPb1P | CW113C | C18700 |
| Wieland | EN Bezeichnung | EN-Nr. | ASTM-UNS-Nr. |
|---|---|---|---|
| K41 | CuNi1Pb1P* | - | C19150 / C19160 |
| K52 | CuNi2Si | CW111C | C70260 |
| K53 | CuNi2SiS* | - | - |
| K54 | CuNi2SiCr* | - | C81540 |
| K60 | CuCr1Zr | CW106C | C18150 |
| K61 | CuCr1Zr | CW106C | C18200 |
| K65 | CuFe2P | CW107C | C19400 |
| K81 | CuSn0,15 | CW117C | C14415 |
| KC1 | CuPb1P | CW113C | C18700 |
| eco KS2® | CuSP | CW114C | C14700 |
| eco KS4® | CuNi1SP* | - | - |
| Wieland | EN Bezeichnung | EN-Nr. | ASTM-UNS-Nr. |
|---|---|---|---|
| K41 | CuNi1Pb1P* | - | C19150 / C19160 |
| K42 | CuZn0,5 | CW119C | - |
| K52 | CuNi2Si | CW111C | C70260 |
| K53 | CuNi2SiS* | - | - |
| K54 | CuNi2SiCr* | - | C81540 |
| K60 | CuCr1Zr | CW106C | C18150 |
| K61 | CuCr1Zr | CW106C | C18200 |
| K65 | CuFe2P | CW107C | C19400 |
| K80 | CuFe0,1P* | - | C19210 |
| K81 | CuSn0,15 | CW117C | C14415 |
| K85 | - | - | C19700 |
| KC1 | CuPb1P | CW113C | C18700 |
