EUCARO 10 (CuNi 90/10 – CuNi10Fe1,6Mn)
Copper-nickel alloys are among the most corrosion-resistant copper materials. Our brand name EUCARO 10 is the benchmark for CuNi90/10 alloys.
We have further developed the standard trade material quality of CuNi10Fe1,6Mn with regard to better processing and longer-term durability, to be able to better exploit the advantages of our material.
Through the optimisation of the alloy components and the minimisation of impurities such as sulphur or phosphorous, our customers receive tubes, flanges and fittings that are fit-for-purpose.
Characteristics
- excellent corrosion resistance, especially against seawater
- good welding and soldering properties
- good cold-workability
- good thermal stability (up to approx.300° C)
- resistant to stress corrosion
- no biofouling
| Mechanical properties | EUCARO ® 10 | |
|---|---|---|
| F 30 | F 32 | |
| 0,2 % proof stress(Rp 0,2), N/ mm² | 100 – 180 | 160 – 220 |
| Tensile strength (RM), N/ mm² | 300 – 400 | 320 – 420 |
| Elongation A5 % | > 30 | > 25 |
| Brinell hardness HB 10 (D²/2,5/62,5) | 70-90 | 80-100 |
| Physical Properties | EUCARO® 10 |
|---|---|
| Density (20 °C), kg/ m³ | 8 900 |
| Specific Heat (20 °C), kg/ m³ | 377 |
| meltinge range, °C | 1 100 – 1 145 |
| Thermal conductivity (20 °C), W/mk | 50 |
| Coeff. of linear exp. (20 - 100 °C), 10-6/K | 17 |
| Electrical resistance (20 °C, annealed), microohm cm | 19 |
| Modulus of elasticity (20 °C, annealed), GN/m² | 138 |
| Designation | DIN | DIN Material Nr. | EN | BS | EEMUA | ASTM | NF |
|---|---|---|---|---|---|---|---|
| EUCARO® 10 | CuNi10Fe1,6Mn (CW 352 H) | 2.1972 | CW 352 H | CN 102 | UNS 7060x | C 70600 | CuNi10Fe1,6Mn (CW 352 H) |
| Designation | Cu | Ni | Fe | Mn | C* | Pb* | S* | Zn* | P* | Zr | Sn | Co | Other | Density kg/ dm³ | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| EUCARO® 10 | min. | Rest | 10,00 | 1,50 | 0,50 | – | – | – | – | – | – | – | – | – | 8,90 |
| max. | Rest | 11,00 | 1,80 | 1,00 | 0,05 | 0,01 | 0,005 | 0,05 | 0,02 | 0,03 | 0,03 | 0,10 | 0,20 | 8,90 |
The reduced impurities in EUCARO10 are an important factor in achieving considerably improved weldability.
