Rods and sectional rods
The right alloy, geometry, and strength – precise and efficient: simply Wieland. Rods and profiled rods are used in a wide range of applications, extending over forged sanitary fittings, lock cylinders and turned parts for machine construction. You can choose from a virtually unlimited number of sizes and geometries.
Special alloys tailored to your specific application are recommended by our Applications Engineering experts.
Our range of products
Our rods and sectional rods at a glance.
The products of Wieland Slaskie are displayed.

ECOBRASS

Hexagonal rod

Machining

Rectangular rod

Round rod

Sectional rod

Square rod

Warm reshaping

ecoline: Lead-free solutions
ECOBRASS

Wieland recognized the potential of environmentally friendly, lead-free machining brass at a very early date, and adopted the pioneering role in Europe by developing ECOBRASS. This proved to be a farsighted course into the future. Today, ECOBRASS is marketed worldwide over a cooperation network and available, even in smaller quantities, from trade partners. We also market this material under the name “CUPHIN” for sanitary products.
Materials
Material designation
Wieland | EN Designation | EN No. | ASTM UNS-No. |
---|---|---|---|
SW1 | CuZn21Si3P | CW724R | C69300 |
Hexagonal rod

Materials
- High-copper alloy
- Machining brass
- Brass
- Special brass
- Phosphor bronze
- Aluminium bronze
- Cast Alloy
- Aluminium
Material designation
Wieland | EN Designation | EN No. | ASTM UNS-No. |
---|---|---|---|
K60 | CuCr1Zr | CW106C | C18150 |
Wieland | EN Designation | EN No. | ASTM UNS-No. | JIS-No. | Dimensions | RoHS compliant | REACH | Temper |
---|---|---|---|---|---|---|---|---|
Z11 | CuZn35Pb1 | CW600N | C34000 | 2.0 – 125.0 mm | yes | Pb > 0.1 | extruded/drawn | |
Z12 | CuZn35Pb2 | CW601N | C34200 / C34500 | 2.0 – 100.0 mm | yes | Pb > 0.1 | extruded/drawn | |
Z21 | CuZn38Pb2 | CW608N | C35000 | C3713 | 2.0 – 125.0 mm | yes | Pb > 0.1 | extruded/drawn |
Z23 | CuZn36Pb3 | CW603N | C36000 | 2.0 – 80.0 mm | yes | Pb > 0.1 | extruded/drawn | |
Z29 | CuZn39Pb2 | CW612N | C37700 | 2.0 – 100.0 mm | yes | Pb > 0.1 | extruded/drawn | |
Z33 | CuZn39Pb3 | CW614N | C38500 | |||||
Z33 | CuZn39Pb3 | CW614N | C38500 | 1.0 – 350.0 mm | yes | Pb > 0.1 | extruded/drawn | |
Z41 | CuZn40Pb2 | CW617N | C38000 | 2.0 – 125.0 mm | yes | Pb > 0.1 | extruded/drawn | |
Z43 | CuZn33Pb1AlSiAs | CW725R | - | 4.0 – 80.0 mm | yes | Pb > 0.1 | extruded/drawn | |
Z45 | CuZn36Pb2As | CW602N | C35330 | 2.0 – 100.0 mm | yes | Pb > 0.1 | extruded/drawn |
Wieland | EN Designation | EN No. | ASTM UNS-No. | JIS-No. | Dimensions |
---|---|---|---|---|---|
M37/M38 | CuZn37 | CW508L | C27200 | C2720 | |
M41 | CuZn38As | CW511L | C27453 | 2.0 – 250.0 mm | |
M57 | CuZn42 | CW510L | - | 2.0 – 250.0 mm |
Wieland | EN Designation | EN No. | ASTM UNS-No. | Dimensions | RoHS compliant | REACH |
---|---|---|---|---|---|---|
S35 | CuZn35Ni3Mn2AlPb | CW710R | - | 2.0 – 130.0 mm | yes | Pb > 0.1 |
S40 | CuZn37Mn3Al2PbSi | CW713R | C67420 | 4.0 – 320.0 mm | yes | Pb > 0.1 |
SW1 | CuZn21Si3P | CW724R | C69300 | 3.0 – 65.0 mm |
Wieland | EN Designation | EN No. | ASTM UNS-No. | JIS-No. | Dimensions |
---|---|---|---|---|---|
B12 | CuSn8P | CW459K | C52100 | 14.0 – 46.0 mm | |
B18 | CuSn8 | CW453K | C52100 | C5212 | 8.0 – 55.0 mm |
Wieland | EN Designation | EN No. | ASTM UNS-No. | Dimensions |
---|---|---|---|---|
U33 | CuAl10Ni5Fe4 | CW307G | C63000 | 10,0 – 70,0 mm |
Wieland | EN Designation | EN No. | ASTM UNS-No. | Dimensions |
---|---|---|---|---|
G07 | CuSn7Zn4Pb7-C | CC493K | - | 17 – 65 mm |
Wieland | EN Designation | EN No. | ASTM UNS-No. | Dimensions | RoHS compliant | REACH | Temper |
---|---|---|---|---|---|---|---|
A01 | AlMgSiBi | AW-6026 | - | on request | yes | extruded/drawn | |
A02 | AlCu6BiPb | AW-2011 | - | from 4 mm | yes | extruded/drawn | |
A03 | AlCu4MgSi(A) | AW-2017A | - | on request | yes | extruded/drawn | |
A07 | AlZn5,5MgCu | AW-7075 | - | on request | yes | extruded/drawn | |
A11 | AlSi1Sn1MgBi | AW-6023 | - | from 13 mm | yes | extruded/drawn | |
A12 | AlMgSiPb | AW-6012 | - | from 10 mm | no | Pb > 0.1 | extruded/drawn |
A22 | AlMgSi | AW-6060 | - | on request | yes | extruded/drawn | |
A24 | - | - | - | on request | yes | extruded/drawn | |
A32 | AlSi1MgMn | AW-6082 | - | from 8 mm | yes | extruded/drawn | |
A66 | - | - | - | from 9 mm | no | Pb > 0.1 | extruded/drawn |
A68 | - | - | - | on request | yes | extruded/drawn | |
A70 | - | - | - | from 13 mm | yes | extruded/drawn | |
A81 | - | - | - | on request | yes | extruded/drawn | |
A83 | - | - | - | from 13 mm | yes | extruded/drawn |
Machining

Rectangular rod

Materials
- Copper
- High-copper alloy
- Machining brass
- Brass
- Special brass
- Phosphor bronze
- Aluminium bronze
- Cast Alloy
- Aluminium
Material designation
Wieland | EN Designation | EN No. | ASTM UNS-No. | JIS-No. | Dimensions | Temper |
---|---|---|---|---|---|---|
K32 | Cu-ETP | CW004A | C11000 | C1100 | 6 × 2 mm – 250 × 12 mm | extruded/drawn |
Wieland | EN Designation | EN No. | ASTM UNS-No. |
---|---|---|---|
K60 | CuCr1Zr | CW106C | C18150 |
Wieland | EN Designation | EN No. | ASTM UNS-No. | JIS-No. | Dimensions | RoHS compliant | REACH | Temper |
---|---|---|---|---|---|---|---|---|
Z21 | CuZn38Pb2 | CW608N | C35000 | C3713 | on request | yes | Pb > 0.1 | extruded/drawn |
Z31 | CuZn40Pb2 | CW617N | C38000 | on request | yes | Pb > 0.1 | extruded/drawn | |
Z33 | CuZn39Pb3 | CW614N | C38500 | 4 × 2 mm bis 150 × 50 mm | ||||
Z43 | CuZn33Pb1AlSiAs | CW725R | - | 2,0 – 125,0 mm | yes | Pb > 0.1 | extruded/drawn | |
Z45 | CuZn36Pb2As | CW602N | C35330 | on request | yes | Pb > 0.1 | extruded/drawn |
Wieland | EN Designation | EN No. | ASTM UNS-No. | JIS-No. | Dimensions | RoHS compliant | REACH | Temper |
---|---|---|---|---|---|---|---|---|
M37/M38 | CuZn37 | CW508L | C27200 | C2720 | ||||
M41 | CuZn38As | CW511L | C27453 | on request | yes | Pb > 0.1 | extruded/drawn | |
M57 | CuZn42 | CW510L | - | on request | yes | Pb > 0.1 | extruded/drawn |
Wieland | EN Designation | EN No. | ASTM UNS-No. | Dimensions | Temper |
---|---|---|---|---|---|
S40 | CuZn37Mn3Al2PbSi | CW713R | C67420 | 10 × 10 – 120 × 120 mm | extruded/drawn |
Wieland | EN Designation | EN No. | ASTM UNS-No. | JIS-No. | Dimensions | Temper |
---|---|---|---|---|---|---|
B12 | CuSn8P | CW459K | C52100 | 20 × 3 – 50 × 35 mm | extruded/drawn | |
B18 | CuSn8 | CW453K | C52100 | C5212 | 20 × 3 – 90 × 30 mm | extruded/drawn |
Wieland | EN Designation | EN No. | ASTM UNS-No. | Dimensions | Temper |
---|---|---|---|---|---|
U33 | CuAl10Ni5Fe4 | CW307G | C63000 | 20 × 10 to 312 × 42 mm | extruded/drawn |
Wieland | EN Designation | EN No. | ASTM UNS-No. | Dimensions | Temper |
---|---|---|---|---|---|
G07 | CuSn7Zn4Pb7-C | CC493K | - | 22 × 12 bis 312 × 52 mm | extruded/drawn |
G12 | CuSn12-C* | CC483K | - | 22 × 12 bis 312 × 52 mm | extruded/drawn |
G91 | CuSn11Pb2-C-GC* | CC482K | - | extruded/drawn |
Wieland | EN Designation | EN No. | ASTM UNS-No. | Dimensions | RoHS compliant | REACH | Temper |
---|---|---|---|---|---|---|---|
A01 | AlMgSiBi | AW-6026 | - | on request | yes | Pb > 0.1 | extruded/drawn |
A02 | AlCu6BiPb | AW-2011 | - | from 10 x 8 mm | yes | Pb > 0.1 | extruded/drawn |
A22 | AlMgSi | AW-6060 | - | from 10 x 2 mm | yes | extruded | |
A24 | - | - | - | on request | yes | extruded/drawn | |
A32 | AlSi1MgMn | AW-6082 | - | from 20 x 10 mm | yes | extruded | |
A66 | - | - | - | from 10 x 8 mm | no | Pb > 0.1 | extruded/drawn |
Round rod

Materials
- Copper
- High-copper alloy
- Machining brass
- Brass
- Special brass
- Phosphor bronze
- Aluminium bronze
- Nickel silver
- Cast Alloy
- Aluminium
Material designation
Wieland | EN Designation | EN No. | ASTM UNS-No. | JIS-No. | Dimensions |
---|---|---|---|---|---|
K20 | Cu-DHP | CW024A | C12200 | ||
K21 | Cu-DHP | CW024A | C12200 | ||
K30 | Cu-OF | CW008A | C10200 | ||
K32 | Cu-ETP | CW004A | C11000 | C1100 | 1.0 – 300.00 mm |
K44 | - | - | C19140 / C19150 | ||
K96 | CuCo1Ni1Be | CW103C | - |
Wieland | EN Designation | EN No. | ASTM UNS-No. | JIS-No. | Dimensions | RoHS compliant | REACH | Temper |
---|---|---|---|---|---|---|---|---|
Z11 | CuZn35Pb1 | CW600N | C34000 | 2.0 – 125.0 mm | yes | Pb > 0.1 | extruded/drawn | |
Z12 | CuZn35Pb2 | CW601N | C34200 / C34500 | 2.0 – 100.0 mm | yes | Pb > 0.1 | extruded/drawn | |
Z21 | CuZn38Pb2 | CW608N | C35000 | C3713 | ||||
Z21 | CuZn38Pb2 | CW608N | C35000 | C3713 | 2.0 – 125.0 mm | yes | Pb > 0.1 | extruded/drawn |
Z23 | CuZn36Pb3 | CW603N | C36000 | |||||
Z23 | CuZn36Pb3 | CW603N | C36000 | 2.0 – 80.0 mm | yes | Pb > 0.1 | extruded/drawn | |
Z29 | CuZn39Pb2 | CW612N | C37700 | 2.0 – 100.0 mm | yes | Pb > 0.1 | extruded/drawn | |
Z33 | CuZn39Pb3 | CW614N | C38500 | 1.0 – 350.0 mm | yes | Pb > 0.1 | extruded/drawn | |
Z41 | CuZn40Pb2 | CW617N | C38000 | |||||
Z41 | CuZn40Pb2 | CW617N | C38000 | 2.0 – 125.0 mm | yes | Pb > 0.1 | extruded/drawn | |
Z43 | CuZn33Pb1AlSiAs | CW725R | - | 4.0 – 80.0 mm | yes | Pb > 0.1 | extruded/drawn | |
Z45 | CuZn36Pb2As | CW602N | C35330 | 2.0 – 100.0 mm | yes | Pb > 0.1 | extruded/drawn | |
Z48 | CuZn40Pb2 | CW617N | C38000 |
Wieland | EN Designation | EN No. | ASTM UNS-No. | JIS-No. | Dimensions | RoHS compliant | REACH | Temper |
---|---|---|---|---|---|---|---|---|
M37/M38 | CuZn37 | CW508L | C27200 | C2720 | 2.0 – 100.0 mm | yes | extruded/drawn | |
M41 | CuZn38As | CW511L | C27453 | 2.0 – 250.0 mm | yes | Pb > 0.1 | extruded/drawn | |
M57 | CuZn42 | CW510L | - | 2.0 – 250.0 mm | yes | Pb > 0.1 | extruded/drawn |
Wieland | EN Designation | EN No. | ASTM UNS-No. | Dimensions | RoHS compliant | REACH |
---|---|---|---|---|---|---|
S35 | CuZn35Ni3Mn2AlPb | CW710R | - | 2.0 – 130.0 mm | yes | Pb > 0.1 |
S40 | CuZn37Mn3Al2PbSi | CW713R | C67420 | |||
S40 | CuZn37Mn3Al2PbSi | CW713R | C67420 | 4.0 – 320.0 mm | yes | Pb > 0.1 |
SW1 | CuZn21Si3P | CW724R | C69300 |
Wieland | EN Designation | EN No. | ASTM UNS-No. | JIS-No. | Dimensions |
---|---|---|---|---|---|
B06 | CuSn6 | CW452K | C51900 | ||
B18 | CuSn8 | CW453K | C52100 | C5212 | 2.0 – 160.0 mm |
Wieland | EN Designation | EN No. | ASTM UNS-No. | Dimensions |
---|---|---|---|---|
CuAl11Ni6Fe6 | - | CW308G | - | 20 – 142,0 mm |
U33 | CuAl10Ni5Fe4 | CW307G | C63000 | 8,0 – 333,0 mm |
Wieland | EN Designation | EN No. | ASTM UNS-No. | Dimensions | Temper |
---|---|---|---|---|---|
N29 | CuNi18Zn20 | CW409J | - | 2.0 – 42,0 mm | extruded |
N31 | CuNi7Zn39Pb3Mn2 | CW400J | - | ||
N32 | CuNi12Zn30Pb1 | CW406J | - | ||
N32 | CuNi12Zn30Pb1 | CW406J | - | 1.5 – 40.0 mm | extruded |
N37 | CuNi18Zn19Pb1 | CW408J | - | 2.0 – 42.0 mm | extruded |
Wieland | EN Designation | EN No. | ASTM UNS-No. | Dimensions |
---|---|---|---|---|
G12 | CuSn12-C* | CC483K | - | 10 – 354 mm |
G22 | CuSn7Pb15-C | CC496K | - | 17 – 187 mm |
G91 | CuSn11Pb2-C-GC* | CC482K | - | 10 – 303 mm |
GB1 | CuSn12Ni2-C | CC484K | - |
Wieland | EN Designation | EN No. | ASTM UNS-No. | Dimensions | RoHS compliant | REACH | Temper |
---|---|---|---|---|---|---|---|
A01 | AlMgSiBi | AW-6026 | - | from 8.0 mm | yes | Pb > 0.1 | extruded/drawn |
A03 | AlCu4MgSi(A) | AW-2017A | - | on request | yes | extruded/drawn | |
A07 | AlZn5,5MgCu | AW-7075 | - | from 7.0 mm | yes | extruded/drawn | |
A11 | AlSi1Sn1MgBi | AW-6023 | - | from 6.0 mm | yes | extruded/drawn | |
A12 | AlMgSiPb | AW-6012 | - | from 3.0 mm | no | Pb > 0.1 | extruded/drawn |
A13 | AlMg3 | AW-5754 | - | on request | yes | extruded/drawn | |
A14 | AlMg4,5Mn0,7 | AW-5083 | - | on request | yes | extruded/drawn | |
A22 | AlMgSi | AW-6060 | - | on request | yes | extruded/drawn | |
A24 | - | - | - | on request | yes | extruded/drawn | |
A32 | AlSi1MgMn | AW-6082 | - | from 2.5 mm | yes | extruded/drawn | |
A66 | - | - | - | from 6.0 mm | no | Pb > 0.1 | extruded/drawn |
A67 | - | - | - | from 2.0 mm | yes | Pb > 0.1 | extruded/drawn |
A68 | - | - | - | on request | yes | extruded/drawn | |
A70 | - | - | - | on request | yes | extruded/drawn | |
A71 | - | - | - | on request | yes | extruded/drawn | |
A76 | - | - | - | on request | yes | extruded/drawn | |
A80 | - | - | - | on request | yes | extruded/drawn | |
A81 | - | - | - | on request | yes | extruded/drawn | |
A83 | - | - | - | from 9.0 mm | yes | extruded/drawn | |
A85 | - | - | - | on request | yes | extruded/drawn |
Sectional rod

Square rod

Materials
- Copper
- High-copper alloy
- Machining brass
- Brass
- Special brass
- Phosphor bronze
- Aluminium bronze
- Cast Alloy
- Aluminium
Material designation
Wieland | EN Designation | EN No. | ASTM UNS-No. | JIS-No. | Dimensions |
---|---|---|---|---|---|
K32 | Cu-ETP | CW004A | C11000 | C1100 | 6 × 6 mm – 140 × 140 mm |
