Products
Our products at a glance
Product categories





Headline
Back to product overviewMold Manufacturing
High-Performance Materials for the Aviation Industry
Round rod
Square rod
Hexagonal rod
Rectangular rod
Precision continuous casting
Sheets and Plates
Tubes

Aluminum Bronze – Plastic Injection Molding Dies for Mold Construction
Benefits
- High tensile and fatigue strength
- Extreme toughness, even at high temperatures up to 400°C
- Thermal conductivity increases as temperature increases
- Excellent resistance to scaling, erosion, and cavitation pitting
- Excellent corrosion resistance, especially in environments with high humidity
- Easy mechanical processing
- Good sliding properties
- Can be used in the delivered condition, no hardening required, thus no warping like with steel
- MIG and TIG welding possible
- Reduced cycle times and production costs by eliminating costly coolant duct systems
Stock/Quality
- We saw to your desired dimensions – fast, clean, and true to size!
- sheets with polished surfaces starting at 4 mm thickness, with milled surfaces from 27 mm to 145 mm thickness
- Pressed bars with edges, straightened: flat from 20x10mm to 160x52mm, square from 20x20mm to 90x90mm
- 100% ultrasonically tested
- Thermally relaxed
- Flatness max. 3 mm/m
Characteristics
Alcaro®AB4S/Sheets | Alcaro®AB4S/Edged Rods | |
Thermal Conductivity W/m×K at approx. room temperature | 50 | 50 |
Thermal Conductivity W/m × K at approx. 300°C | 73 | 73 |
Tensile Strength Rm N/mm² approx. | 720 | 720 |
Yield Strength Rp0.2 N/mm² ca. | 320 – 370 | 480 – 530 |
Brinell Hardness HB ca. | 200 | |
Vickers Hardness HV ca. | 180 | |
Ultimate Strain A5 % approx. | 20 | 10 |
Expansion Coefficient 10-6/K | 17 | 17 |
Machining information
Material: Alcaro®AB4S/Sheets
Turning/Milling | Excellent |
Polishability | Excellent |
Wire EDM | Excellent |
Die-Sinking EDM | Good |
Thread Cutting | Good, Sharp |
Welding (WIG) | Good |
Galvanic Surface Treatment | Good |
Drilling | Good |

We supply aerospace grade alloys and special alloys of the highest quality. For the aerospace industry Wieland Prometa offers you high-quality semi-finished products in a wide range of dimensions.
The outstanding mechanical properties and a very good machinability make our products ideal materials for bushings, bearings and connections for the highest loads.
Brochure: Ready for takeoff
Materials
Alloy Number | Composition | Standards | |
---|---|---|---|
C65620 | CuZn3Si3Fe2Mn | AMS 4616 F&G | |
C70260 | CW111C | CuNi2Si | CARODUR®-2 |
Further alloys on request.
Alloy Number | Composition | Temper | Standards | |
---|---|---|---|---|
C62300 | CuAl8Fe3 | HR50/ O30 | AMS 4635 | |
C62400 | CuAl10Fe3 | ASTM B150 | ||
C63000 | CW307G | CuAl10Ni5Fe4 | HR50/ TQ50 | EN 12163 |
C63020 | CW307G CA104 | CuAl10Ni5Fe4 | HR50/ TQ30 | EN 12163 |
C63200 | CuAl9Ni4Fe3 | TQ50 | ASTM B150 | |
C95510 | CuAl10Ni5Fe2 | TQ50 | AMS 4880 | |
C95520 | CuAl11Ni5Fe4 | TQ50 | AMS 4881 | |
CuAl9Ni5Fe4 | DEF NES 02-833 |
Further alloys on request.
Alloy Number | Composition | Standards | |
---|---|---|---|
C51000 | CW451K | CuSn5 | AMS 4625 |
C52100 | CW459K | CuSn8P | PB 104 |
Further alloys on request.

Materials
Wieland | EN Designation | EN No. | ASTM UNS-No. | JIS-No. | Dimensions | Temper |
---|---|---|---|---|---|---|
K18 | Cu-ETP | CW004A | C11000 | 5 – 150 mm | R250/R300/D/M | |
K20/K21/K28 | Cu-DHP | CW024A | C12200 | |||
K20/K21/K28 | Cu-DHP | CW024A | C12200 | |||
K30 | Cu-OF | CW008A | C10200 | |||
K32 | Cu-ETP | CW004A | C11000 | C1100 | 1.0 – 300.00 mm |
Wieland | EN Designation | EN No. | ASTM UNS-No. | Dimensions | Temper |
---|---|---|---|---|---|
K41 | CuNi1Pb1P* | - | C19150 / C19160 | ||
K44 | - | - | C19140 / C19150 | ||
K52 | CuNi2Si | CW111C | C70260 | 10 - 40 mm | hardened |
K54 | CuNi2SiCr* | - | C81540 | 67 - 148 mm | hardened |
KC1 | CuPb1P | CW113C | C18700 |
Wieland | EN Designation | EN No. | ASTM UNS-No. | JIS-No. | Dimensions | RoHS compliant | REACH | Temper |
---|---|---|---|---|---|---|---|---|
Z11 | CuZn35Pb1 | CW600N | C34000 | 2.0 – 125.0 mm | yes | Pb > 0.1 | extruded/drawn | |
Z12 | CuZn35Pb2 | CW601N | C34200 / C34500 | 2.0 – 100.0 mm | yes | Pb > 0.1 | extruded/drawn | |
Z21 | CuZn38Pb2 | CW608N | C3713 | 2.0 – 125.0 mm | yes | Pb > 0.1 | extruded/drawn | |
Z23 | CuZn36Pb3 | CW603N | C36000 | 2.0 – 80.0 mm | yes | Pb > 0.1 | extruded/drawn | |
Z29 | CuZn39Pb2 | CW612N | C37700 | 2.0 – 100.0 mm | yes | Pb > 0.1 | extruded/drawn | |
Z31/Z41/Z48 | CuZn40Pb2 | CW617N | C38000 | 2.0 – 125.0 mm | yes | Pb > 0.1 | extruded/drawn | |
Z31/Z41/Z48 | CuZn40Pb2 | CW617N | C38000 | 3 – 90 mm | R500/R430/M | |||
Z32/Z33 | CuZn39Pb3 | CW614N | C38500 | |||||
Z32/Z33 | CuZn39Pb3 | CW614N | C38500 | |||||
Z32/Z33 | CuZn39Pb3 | CW614N | C38500 | 1.8 – 80.0 mm | yes | Pb > 0.1 | extruded/drawn | |
Z32/Z33 | CuZn39Pb3 | CW614N | C38500 | 1.0 – 350.0 mm | yes | Pb > 0.1 | extruded/drawn | |
Z32/Z33 | CuZn39Pb3 | CW614N | C38500 | 3 – 90 mm | R500/R430/M | |||
Z43 | CuZn33Pb1AlSiAs | CW725R | - | 4.0 – 80.0 mm | yes | Pb > 0.1 | extruded/drawn | |
Z43 | CuZn33Pb1AlSiAs | CW725R | - | |||||
Z45 | CuZn36Pb2As | CW602N | C35330 | 2.0 – 100.0 mm | yes | Pb > 0.1 | extruded/drawn |
Wieland | EN Designation | EN No. | ASTM UNS-No. | JIS-No. | Dimensions | RoHS compliant | REACH | Temper |
---|---|---|---|---|---|---|---|---|
M37/M38 | CuZn37 | CW508L | C27200 | C2720 | 2.0 – 100.0 mm | yes | extruded/drawn | |
eco M41® | CuZn38As | CW511L | C27453 | 2.0 – 250.0 mm | yes | Pb > 0.1 | extruded/drawn | |
eco M41® | CuZn38As | CW511L | C27453 | 12 – 80 mm | R280-R400 | |||
eco M57® | CuZn42 | CW510L | - | 2.0 – 250.0 mm | yes | Pb > 0.1 | extruded/drawn | |
eco M57® | CuZn42 | CW510L | - | 12 – 80 mm | R360-R500 |
Wieland | EN Designation | EN No. | ASTM UNS-No. | Dimensions | RoHS compliant | REACH | Temper |
---|---|---|---|---|---|---|---|
S31 | CuZn31Si1 | CW708R | - | ||||
S35 | CuZn35Ni3Mn2AlPb | CW710R | - | 2.0 – 130.0 mm | yes | Pb > 0.1 | |
S35 | CuZn35Ni3Mn2AlPb | CW710R | - | ||||
S35 | CuZn35Ni3Mn2AlPb | CW710R | - | 8 - 130 mm | extruded/drawn | ||
S40 | CuZn37Mn3Al2PbSi | CW713R | C67420 | 4.0 – 320.0 mm | yes | Pb > 0.1 | |
S40 | CuZn37Mn3Al2PbSi | CW713R | C67420 | ||||
eco SW1® | CuZn21Si3P | CW724R | C69300 | 3.0 – 100.0 mm | yes | extruded | |
eco SW1® | CuZn21Si3P | CW724R | C69300 | 3 – 70 mm | R500-R670 |
Wieland | EN Designation | EN No. | ASTM UNS-No. | Dimensions |
---|---|---|---|---|
B06 | CuSn6 | CW452K | C51900 | |
B12/B21 | CuSn8P/CuSn8 | CW459K/CW453K | C52100 | 4.0 – 125.0 mm |
B44 | CuSn4Pb4Zn4 | CW456K | C54400 |
Wieland | EN Designation | EN No. | ASTM UNS-No. | Dimensions | Temper |
---|---|---|---|---|---|
U33 | CuAl10Ni5Fe4 | CW307G | C63000 | 8,0 – 333,0 mm | |
U33 | CuAl10Ni5Fe4 | CW307G | C63000 | 8 – 162 mm | extruded/drawn |
U36 | CuAl11Fe6Ni6 | CW308G | - | 20 – 142 mm | extruded/drawn |
U39 | Cu Al10Fe3Mn2 | CW306G | - | ||
U39 | Cu Al10Fe3Mn2 | CW306G | - | 16 - 140 mm | extruded |
Wieland | EN Designation | EN No. | ASTM UNS-No. | Dimensions | Temper |
---|---|---|---|---|---|
N29 | CuNi18Zn20 | CW409J | - | 2.0 – 42,0 mm | extruded |
N32 | CuNi12Zn30Pb1 | CW406J | - | 1.5 – 40.0 mm | extruded |
N37 | CuNi18Zn19Pb1 | CW408J | - | 2.0 – 42.0 mm | extruded |
Wieland | EN Designation | EN No. | ASTM UNS-No. | Dimensions | RoHS compliant | REACH | Temper |
---|---|---|---|---|---|---|---|
A01 | AlMgSiBi | AW-6026 | - | from 8.0 mm | yes | Pb > 0.1 | extruded/drawn |
A01 | AlMgSiBi | AW-6026 | - | on request | yes | extruded/drawn | |
A03 | AlCu4MgSi(A) | AW-2017A | - | on request | yes | extruded/drawn | |
A07 | AlZn5,5MgCu | AW-7075 | - | from 7.0 mm | yes | extruded/drawn | |
A07 | AlZn5,5MgCu | AW-7075 | - | from rd. 15 mm | extruded/drawn | ||
A11 | AlSi1Sn1MgBi | AW-6023 | - | from 6.0 mm | yes | extruded/drawn | |
A12 | AlMgSiPb | AW-6012 | - | from 3.0 mm | no | Pb > 0.1 | extruded/drawn |
A13 | AlMg3 | AW-5754 | - | on request | yes | extruded/drawn | |
A14 | AlMg4,5Mn0,7 | AW-5083 | - | on request | yes | extruded/drawn | |
A22 | AlMgSi | AW-6060 | - | on request | yes | extruded/drawn | |
A24 | - | - | - | on request | yes | extruded/drawn | |
A32 | AlSi1MgMn | AW-6082 | - | from 2.5 mm | yes | extruded/drawn | |
A32 | AlSi1MgMn | AW-6082 | - | 15 – 40 mm x 3.000 mm | T6 | ||
A66 | - | - | - | from 6.0 mm | no | Pb > 0.1 | extruded/drawn |
A66 | - | - | - | ab rd. 15 mm | extruded/drawn | ||
A67 | - | - | - | from 2.0 mm | yes | Pb > 0.1 | extruded/drawn |
A68 | - | - | - | on request | yes | extruded/drawn | |
A70 | - | - | - | on request | yes | extruded/drawn | |
A71 | - | - | - | on request | yes | extruded/drawn | |
A76 | - | - | - | on request | yes | extruded/drawn | |
A80 | - | - | - | on request | yes | extruded/drawn | |
A81 | - | - | - | on request | yes | extruded/drawn | |
A83 | - | - | - | from 9.0 mm | yes | extruded/drawn | |
A85 | - | - | - | on request | yes | extruded/drawn |

Wieland | EN Designation | EN No. | ASTM UNS-No. | JIS-No. | Dimensions |
---|---|---|---|---|---|
K32 | Cu-ETP | CW004A | C11000 | C1100 | 6 × 6 mm – 140 × 140 mm |
Wieland | EN Designation | EN No. | ASTM UNS-No. | JIS-No. | Dimensions | Temper |
---|---|---|---|---|---|---|
Z12 | CuZn35Pb2 | CW601N | C34200 / C34500 | 2,0 – 100,0 mm | ||
Z21 | CuZn38Pb2 | CW608N | C3713 | 2,0 – 125,0 mm | ||
Z31 | CuZn40Pb2 | CW617N | C38000 | on request | M | |
Z32 | CuZn39Pb3 | CW614N | C38500 | 5 × 2 – 100 × 20 mm | M | |
Z33 | CuZn39Pb3 | CW614N | C38500 | 2,0 – 250,0 mm | ||
Z43 | CuZn33Pb1AlSiAs | CW725R | - | 2,0 – 125,0 mm |
Wieland | EN Designation | EN No. | ASTM UNS-No. | Dimensions |
---|---|---|---|---|
eco M41® | CuZn38As | CW511L | C27453 | on request |
eco M57® | CuZn42 | CW510L | - | on request |
Wieland | EN Designation | EN No. | ASTM UNS-No. | Dimensions | RoHS compliant | REACH |
---|---|---|---|---|---|---|
S35 | CuZn35Ni3Mn2AlPb | CW710R | - | 14.0 – 60.0 mm | yes | Pb > 0.1 |
S40 | CuZn37Mn3Al2PbSi | CW713R | C67420 | 14.0 – 60.0 mm | yes | Pb > 0.1 |
eco SW1® | CuZn21Si3P | CW724R | C69300 | on request |
Wieland | EN Designation | EN No. | ASTM UNS-No. | Dimensions |
---|---|---|---|---|
B12/B21 | CuSn8P/CuSn8 | CW459K/CW453K | C52100 | 8 × 8 – 40 × 40 mm |
Wieland | EN Designation | EN No. | ASTM UNS-No. |
---|---|---|---|
U33 | CuAl10Ni5Fe4 | CW307G | C63000 |
Wieland | EN Designation | EN No. | ASTM UNS-No. | Dimensions | RoHS compliant | REACH | Temper |
---|---|---|---|---|---|---|---|
A01 | AlMgSiBi | AW-6026 | - | from 15 x 15 mm | yes | Pb > 0.1 | extruded/drawn |
A01 | AlMgSiBi | AW-6026 | - | on request | yes | extruded/drawn | |
A02 | AlCu6BiPb | AW-2011 | - | from 4 x 4 mm | yes | Pb > 0.1 | extruded/drawn |
A03 | AlCu4MgSi(A) | AW-2017A | - | on request | yes | extruded/drawn | |
A11 | AlSi1Sn1MgBi | AW-6023 | - | on request | yes | extruded/drawn | |
A12 | AlMgSiPb | AW-6012 | - | on request | no | Pb > 0.1 | extruded/drawn |
A22 | AlMgSi | AW-6060 | - | from 6 x 6 mm | yes | extruded/drawn | |
A24 | - | - | - | on request | yes | extruded/drawn | |
A32 | AlSi1MgMn | AW-6082 | - | from 8 x 8 mm | yes | extruded/drawn | |
A66 | - | - | - | from 10 x 10 mm | no | Pb > 0.1 | extruded/drawn |
A66 | - | - | - | 30x30 to 200x200 mm | extruded/drawn | ||
A66 | - | - | - | 70x20 to 200x100 mm | extruded/drawn | ||
A68 | - | - | - | on request | yes | extruded/drawn | |
A70 | - | - | - | on request | yes | extruded/drawn | |
A81 | - | - | - | on request | yes | extruded/drawn | |
A83 | - | - | - | on request | yes | extruded/drawn |

Materials
Wieland | EN Designation | EN No. | ASTM UNS-No. | Dimensions | Temper |
---|---|---|---|---|---|
K52 | CuNi2Si | CW111C | C70260 | 19 - 36 mm | drawn/hardened |
Wieland | EN Designation | EN No. | ASTM UNS-No. | JIS-No. | Dimensions | RoHS compliant | REACH | Temper |
---|---|---|---|---|---|---|---|---|
Z11 | CuZn35Pb1 | CW600N | C34000 | 2.0 – 125.0 mm | yes | Pb > 0.1 | extruded/drawn | |
Z12 | CuZn35Pb2 | CW601N | C34200 / C34500 | 2.0 – 100.0 mm | yes | Pb > 0.1 | extruded/drawn | |
Z21 | CuZn38Pb2 | CW608N | C3713 | 2.0 – 125.0 mm | yes | Pb > 0.1 | extruded/drawn | |
Z23 | CuZn36Pb3 | CW603N | C36000 | 2.0 – 80.0 mm | yes | Pb > 0.1 | extruded/drawn | |
Z29 | CuZn39Pb2 | CW612N | C37700 | 2.0 – 100.0 mm | yes | Pb > 0.1 | extruded/drawn | |
Z31/Z41/Z48 | CuZn40Pb2 | CW617N | C38000 | 2.0 – 125.0 mm | yes | Pb > 0.1 | extruded/drawn | |
Z31/Z41/Z48 | CuZn40Pb2 | CW617N | C38000 | 5 – 70 mm | R500/R430/M | |||
Z32/Z33 | CuZn39Pb3 | CW614N | C38500 | 1.8 – 80.0 mm | yes | Pb > 0.1 | extruded/drawn | |
Z32/Z33 | CuZn39Pb3 | CW614N | C38500 | 1.0 – 350.0 mm | yes | Pb > 0.1 | extruded/drawn | |
Z32/Z33 | CuZn39Pb3 | CW614N | C38500 | 5 – 70 mm | R500/R430/M | |||
Z43 | CuZn33Pb1AlSiAs | CW725R | - | 4.0 – 80.0 mm | yes | Pb > 0.1 | extruded/drawn | |
Z45 | CuZn36Pb2As | CW602N | C35330 | 2.0 – 100.0 mm | yes | Pb > 0.1 | extruded/drawn |
Wieland | EN Designation | EN No. | ASTM UNS-No. | JIS-No. | Dimensions | RoHS compliant | Temper |
---|---|---|---|---|---|---|---|
M37/M38 | CuZn37 | CW508L | C27200 | C2720 | 2.0 – 100.0 mm | yes | extruded/drawn |
eco M41® | CuZn38As | CW511L | C27453 | 2.0 – 250.0 mm | |||
eco M57® | CuZn42 | CW510L | - | 2.0 – 250.0 mm |
Wieland | EN Designation | EN No. | ASTM UNS-No. | Dimensions |
---|---|---|---|---|
S35 | CuZn35Ni3Mn2AlPb | CW710R | - | |
S35 | CuZn35Ni3Mn2AlPb | CW710R | - | 11 - 60 mm |
S40 | CuZn37Mn3Al2PbSi | CW713R | C67420 | |
eco SW1® | CuZn21Si3P | CW724R | C69300 | 3.0 – 65.0 mm |
Wieland | EN Designation | EN No. | ASTM UNS-No. | Dimensions |
---|---|---|---|---|
B12/B21 | CuSn8P/CuSn8 | CW459K/CW453K | C52100 | 14.0 – 46.0 mm |
Wieland | EN Designation | EN No. | ASTM UNS-No. | Dimensions |
---|---|---|---|---|
U33 | CuAl10Ni5Fe4 | CW307G | C63000 | 10,0 – 70,0 mm |
U33 | CuAl10Ni5Fe4 | CW307G | C63000 | 13 - 65 mm |
Wieland | EN Designation | EN No. | ASTM UNS-No. | Dimensions | RoHS compliant | REACH | Temper |
---|---|---|---|---|---|---|---|
A01 | AlMgSiBi | AW-6026 | - | from 12 mm | yes | Pb > 0.1 | extruded/drawn |
A01 | AlMgSiBi | AW-6026 | - | on request | yes | extruded/drawn | |
A02 | AlCu6BiPb | AW-2011 | - | from 4 mm | yes | extruded/drawn | |
A03 | AlCu4MgSi(A) | AW-2017A | - | on request | yes | extruded/drawn | |
A07 | AlZn5,5MgCu | AW-7075 | - | on request | yes | extruded/drawn | |
A11 | AlSi1Sn1MgBi | AW-6023 | - | from 13 mm | yes | extruded/drawn | |
A12 | AlMgSiPb | AW-6012 | - | from 10 mm | no | Pb > 0.1 | extruded/drawn |
A22 | AlMgSi | AW-6060 | - | on request | yes | extruded/drawn | |
A24 | - | - | - | on request | yes | extruded/drawn | |
A32 | AlSi1MgMn | AW-6082 | - | from 8 mm | yes | extruded/drawn | |
A66 | - | - | - | from 9 mm | no | Pb > 0.1 | extruded/drawn |
A68 | - | - | - | on request | yes | extruded/drawn | |
A70 | - | - | - | from 13 mm | yes | extruded/drawn | |
A81 | - | - | - | on request | yes | extruded/drawn | |
A83 | - | - | - | from 13 mm | yes | extruded/drawn |

Wieland | EN Designation | EN No. | ASTM UNS-No. | JIS-No. | Dimensions | Temper |
---|---|---|---|---|---|---|
K18 | Cu-ETP | CW004A | C11000 | 10 × 3 – 200 × 10 mm | R250/R300/D | |
K32 | Cu-ETP | CW004A | C11000 | C1100 | 6 × 2 mm – 250 × 12 mm | extruded/drawn |
Wieland | EN Designation | EN No. | ASTM UNS-No. | JIS-No. | Dimensions | RoHS compliant | REACH | Temper |
---|---|---|---|---|---|---|---|---|
Z21 | CuZn38Pb2 | CW608N | C3713 | on request | yes | Pb > 0.1 | extruded/drawn | |
Z31 | CuZn40Pb2 | CW617N | C38000 | on request | yes | Pb > 0.1 | extruded/drawn | |
Z31 | CuZn40Pb2 | CW617N | C38000 | 4 – 60 mm | R500/R430/M | |||
Z32 | CuZn39Pb3 | CW614N | C38500 | 4 – 60 mm | R500/R430/M | |||
Z33 | CuZn39Pb3 | CW614N | C38500 | 4 × 2 mm bis 150 × 50 mm | ||||
Z43 | CuZn33Pb1AlSiAs | CW725R | - | 2,0 – 125,0 mm | yes | Pb > 0.1 | extruded/drawn | |
Z45 | CuZn36Pb2As | CW602N | C35330 | on request | yes | Pb > 0.1 | extruded/drawn |
Wieland | EN Designation | EN No. | ASTM UNS-No. | JIS-No. | Dimensions | RoHS compliant | REACH | Temper |
---|---|---|---|---|---|---|---|---|
M37/M38 | CuZn37 | CW508L | C27200 | C2720 | on request | yes | Pb > 0.1 | extruded/drawn |
eco M41® | CuZn38As | CW511L | C27453 | on request | yes | Pb > 0.1 | extruded/drawn | |
eco M57® | CuZn42 | CW510L | - | on request | yes | Pb > 0.1 | extruded/drawn |
Wieland | EN Designation | EN No. | ASTM UNS-No. | Dimensions | Temper |
---|---|---|---|---|---|
S40 | CuZn37Mn3Al2PbSi | CW713R | C67420 | 10 × 10 – 120 × 120 mm | extruded/drawn |
S40 | CuZn37Mn3Al2PbSi | CW713R | C67420 | 20 × 10 – 80 × 40 mm | extruded/drawn |
Wieland | EN Designation | EN No. | ASTM UNS-No. | Dimensions | Temper |
---|---|---|---|---|---|
B12/B21 | CuSn8P/CuSn8 | CW459K/CW453K | C52100 | 20 × 3 – 50 × 35 mm | extruded/drawn |
Wieland | EN Designation | EN No. | ASTM UNS-No. | Dimensions | Temper |
---|---|---|---|---|---|
U33 | CuAl10Ni5Fe4 | CW307G | C63000 | 20x10 to 160x52 mm | extruded |
U33 | CuAl10Ni5Fe4 | CW307G | C63000 | ||
U33 | CuAl10Ni5Fe4 | CW307G | C63000 | 20x20 bis 90x90 mm | extruded |
Wieland | EN Designation | EN No. | ASTM UNS-No. | Dimensions | RoHS compliant | REACH | Temper |
---|---|---|---|---|---|---|---|
A01 | AlMgSiBi | AW-6026 | - | on request | yes | Pb > 0.1 | extruded/drawn |
A01 | AlMgSiBi | AW-6026 | - | on request | yes | extruded/drawn | |
A02 | AlCu6BiPb | AW-2011 | - | from 10 x 8 mm | yes | Pb > 0.1 | extruded/drawn |
A22 | AlMgSi | AW-6060 | - | from 10 x 2 mm | yes | extruded | |
A24 | - | - | - | on request | yes | extruded/drawn | |
A32 | AlSi1MgMn | AW-6082 | - | from 20 x 10 mm | yes | extruded | |
A66 | - | - | - | from 10 x 8 mm | no | Pb > 0.1 | extruded/drawn |

From Europe’s largest copper alloy foundry in Vöhringen/Iller (Germany), we can offer you far in excess of a hundred different copper materials. These include not only a wide range of continuous castings like tubes and rods, but also shaped rods and sections of complex geometries. At the same time, our flexibility ensures the prompt realisation of your special custom wishes.
Materials
Wieland | EN Designation | EN No. | ASTM UNS-No. | Dimensions |
---|---|---|---|---|
G07/G08 | CuSn7Zn4Pb7-C | CC493K | - | 10 – 354 mm |
G07/G08 | CuSn7Zn4Pb7-C | CC493K | - | 17 – 65 mm |
G07/G08 | CuSn7Zn4Pb7-C | CC493K | - | 22 × 22 bis 203 × 203 mm |
G07/G08 | CuSn7Zn4Pb7-C | CC493K | - | 22 × 12 bis 312 × 52 mm |
G07/G08 | CuSn7Zn4Pb7-C | CC493K | - | 10 - 404 mm |
G07/G08 | CuSn7Zn4Pb7-C | CC493K | - | 22x22 bis 113x113 mm |
G07/G08 | CuSn7Zn4Pb7-C | CC493K | - | 32x12 to 123x23 mm |
G07/G08 | CuSn7Zn4Pb7-C | CC493K | - | |
G12/G13 | CuSn12-C | CC483K | - | 10 – 354 mm |
G12/G13 | CuSn12-C | CC483K | - | 22 × 22 bis 203 × 203 mm |
G12/G13 | CuSn12-C | CC483K | - | 22 × 12 bis 312 × 52 mm |
G12/G13 | CuSn12-C | CC483K | - | |
G12/G13 | CuSn12-C | CC483K | - | |
G12/G13 | CuSn12-C | CC483K | - | |
G22 | CuSn7Pb15-C | CC496K | - | |
G91 | CuSn11Pb2-C-GC | CC482K | - | 10 – 303 mm |
G91 | CuSn11Pb2-C-GC | CC482K | - | on request |
G91 | CuSn11Pb2-C-GC | CC482K | - | |
G91 | CuSn11Pb2-C-GC | CC482K | - | |
GB1 | CuSn12Ni2-C | CC484K | - |

Wieland | EN Designation | EN No. | ASTM UNS-No. | JIS-No. | Dimensions | Temper |
---|---|---|---|---|---|---|
K11 | Cu-OF | CW008A | C10200 | R220/R240/R290/R360 F20/F25/F32 | ||
K12 | Cu-HCP | CW021A | C10300 | |||
K12 | Cu-HCP | CW021A | C10300 | R220/R240/R290/R360 F20/F25/F33 | ||
K14 | Cu-PHC | CW020A | C10300 | |||
K14 | Cu-PHC | CW020A | C10300 | R220/R240/R290/R360 F20/F25/F34 | ||
K18 | Cu-ETP | CW004A | C11000 | |||
K19 | Cu-DHP | CW024A | C12200 | C1220 | ||
K19 | Cu-DHP | CW024A | C12200 | C1220 | R220/R240/R290/R360 F20/F25/F31 | |
K32 | Cu-ETP | CW004A | C11000 | C1100 | 0.3 – 150 mm | R220/R240/R290/R360 F20/F25/F30 |
Wieland | EN Designation | EN No. | ASTM UNS-No. | Dimensions | RoHS compliant | Temper |
---|---|---|---|---|---|---|
Z29 | CuZn39Pb2 | CW612N | C37700 | 0.3 – 60 mm | R490 | |
Z30 | CuZn39Pb2 | CW612N | C37700 | 0.3 – 120 mm | Yes | R360/R490/R560 F36/F49/F59 |
Wieland | EN Designation | EN No. | ASTM UNS-No. | JIS-No. | Dimensions | Temper |
---|---|---|---|---|---|---|
M15 | CuZn15 | CW502L | C23000 | C2300 | R260/R350 F26/F37 | |
M37 | CuZn37 | CW508L | C27200 | C2720 | 0.3 – 60 mm | R300, R350, R410 |
M38 | CuZn37 | CW508L | C27200 | C2720 | 0.2 –10 mm | R300/R350/R480/R550 F30/F37/F44/F54 |
Wieland | EN Designation | EN No. | ASTM UNS-No. | Dimensions | Temper |
---|---|---|---|---|---|
B06 | CuSn6 | CW452K | C51900 | 0,2 - 40 mm Dicke | hard/spring-tempered roll-hardened |
B16 | CuSn6 | CW452K | C51900 | 0.10 – 3.0 mm | R350/R420/R500/R560/R640/R720 H080/H125/H160/H180/H200/H220 |
Wieland | EN Designation | EN No. | ASTM UNS-No. |
---|---|---|---|
U33 | CuAl10Ni5Fe4 | CW307G | C63000 |
Wieland | EN Designation | EN No. | ASTM UNS-No. | JIS-No. | Dimensions | Temper |
---|---|---|---|---|---|---|
N12 | CUNi12Zn24 | CW403J | C75700 | 0.4 – 5.0 mm (600 × 2000) | R360/R430/R490/R550/R620 | |
N18 | CuNi18Zn20 | CW409J | C76400 | C7521 | 0,10 – 1.5 mm (300 × 2000) | R380/R450/R500/R580/R640 |
Wieland | EN Designation | EN No. | ASTM UNS-No. | Dimensions |
---|---|---|---|---|
A05 | Al99,5 | AW-1050A | - | 1000 × 2000 mm, 1250 × 2500 mm, 1500 × 3000 mm |
A05 | Al99,5 | AW-1050A | - | |
A13 | AlMg3 | AW-5754 | - | 1000 × 2000 mm, 1250 × 2500 mm, 1500 × 3000 mm |
A13 | AlMg3 | AW-5754 | - | |
A32 | AlSi1MgMn | AW-6082 | - | |
A75 | AW-6082 | - | - | 1000 × 2000 mm, 1250 × 2500 mm, 1500 × 3000 mm |
A75 | AW-6082 | - | - |

Wieland | EN Designation | EN No. | ASTM UNS-No. | JIS-No. |
---|---|---|---|---|
K20/K21/K28 | Cu-DHP | CW024A | C12200 | |
K32 | Cu-ETP | CW004A | C11000 | C1100 |
Wieland | EN Designation | EN No. | ASTM UNS-No. | JIS-No. |
---|---|---|---|---|
Z11 | CuZn35Pb1 | CW600N | C34000 | |
Z21 | CuZn38Pb2 | CW608N | C3713 | |
Z21 | CuZn38Pb2 | CW608N | C3713 | |
Z31 | CuZn40Pb2 | CW617N | C38000 | |
Z31 | CuZn40Pb2 | CW617N | C38000 | |
Z33 | CuZn39Pb3 | CW614N | C38500 | |
Z33 | CuZn39Pb3 | CW614N | C38500 | |
Z35 | CuZn36Pb2As | CW602N | C35330 | |
Z45 | CuZn36Pb2As | CW602N | C35330 |
Wieland | EN Designation | EN No. | ASTM UNS-No. | JIS-No. | Dimensions | Temper |
---|---|---|---|---|---|---|
M32 | - | - | C26000 | |||
M37 | CuZn37 | CW508L | C27200 | C2720 | ||
M38 | CuZn37 | CW508L | C27200 | C2720 | m | m |
eco M41® | CuZn38As | CW511L | C27453 | extruded/drawn | ||
eco M57® | CuZn42 | CW510L | - | extruded/drawn |
Wieland | EN Designation | EN No. | ASTM UNS-No. |
---|---|---|---|
S40 | CuZn37Mn3Al2PbSi | CW713R | C67420 |
Wieland | EN Designation | EN No. | ASTM UNS-No. |
---|---|---|---|
B12 | CuSn8P | CW459K | C52100 |
Wieland | EN Designation | EN No. | ASTM UNS-No. |
---|---|---|---|
A05 | Al99,5 | AW-1050A | - |
A13 | AlMg3 | AW-5754 | - |
A22 | AlMgSi | AW-6060 | - |
A32 | AlSi1MgMn | AW-6082 | - |
A66 | - | - | - |
